Pewag
Pewag VLWI13 1/2" Grade 63 Stainless Steel Adjusting Link - 9300 lbs WLL
Made in Austria.
This product is rated for overhead lifting.
Need it fast? We stock many items, but some rigging and safety gear has longer lead times. Contact us before placing urgent orders.
Earn rewards points.
CA Prop 65
Product Description
Pewag VLWI Grade 63 Stainless Chain Shortener — Precision Adjustment for Stainless Lifting Systems
The Pewag VLWI Grade 63 Chain Shortener is a compact, corrosion-resistant component designed for link-by-link adjustment of Pewag WOX Grade 63 stainless steel chain. Each unit includes a welded-in BWI transition link, making it quick and simple to shorten or adjust sling length while maintaining full lifting capacity. Built from high-grade stainless steel, the VLWI shortener delivers superior durability in marine, wastewater, food, and chemical environments.
Key Features
- Grade 63 stainless steel — fully rated for overhead lifting
- Welded-in BWI transition link for secure connection and quick use
- Allows link-by-link chain shortening without disassembly
- Highly corrosion resistant for demanding environments
- Compatible with WOX chain, AWI/VWI master links, and CWI connectors
VLWI Grade 63 Specifications
| Code | Chain Size (in.) | WLL (lbs) | Reach (in.) | Weight (lbs) |
|---|---|---|---|---|
| VLWI 5/6-6 | 3/16" – 7/32" | 2,000 | 4.49 | 0.49 |
| VLWI 7/8-6 | 9/32" – 5/16" | 3,500 | 6.14 | 1.26 |
| VLWI 10-6 | 3/8" | 5,500 | 7.32 | 2.34 |
| VLWI 13-6 | 1/2" | 9,300 | 9.53 | 4.89 |
| VLWI 16-6 | 5/8" | 13,900 | 11.18 | 9.17 |
All data per Pewag specifications. The VLWI Shortener is tested at 100% of rated capacity and should only be used with matching Pewag Grade 63 components for certified lifting service.
