Pewag
Pewag WOX13 1/2" Grade 63 Stainless Steel Chain - 9300 lbs WLL
Made in Austria.
This product is rated for overhead lifting.
Full Drum Length: 200 feet
Need it fast? We stock many items, but some rigging and safety gear has longer lead times. Contact us before placing urgent orders.
This product is not returnable.
Earn rewards points.
CA Prop 65
Product Description
Superior Corrosion Resistance and Strength — Pewag WOX Grade 63 Stainless Steel Chain
The Pewag WOX Stainless Steel Chain is part of Pewag’s Grade 63 “Winner Inox” lineup, engineered specifically for overhead lifting applications. When paired with matching Pewag Grade 63 fittings—such as AWI master links and CWI connecting links—the WOX chain forms a complete certified Grade 63 chain sling assembly ready for demanding lifting environments.
Compared to conventional Grade 50 stainless chain, WOX delivers a 25% higher working load limit for the same nominal diameter. Each link is electrically welded, proof-tested to 100% of its rated capacity, and stamped for traceability. With exceptional resistance to acids and caustics, it’s ideal for marine, wastewater, chemical, and food-processing applications.
Key Features
- Grade 63 stainless steel — fully rated for overhead lifting
- 25% higher WLL than Grade 50 stainless chain of the same size
- 100% proof-tested and permanently stamped for traceability
- Electrically welded links for a smooth, corrosion-resistant finish
- Excellent acid and caustic resistance vs. Grade 80, 100, 120 alloy chains
- Compatible with AWI master links and CWI connectors for matched Grade 63 assemblies
- Designed for marine, wastewater, and food-grade lifting conditions
WOX Grade 63 Specifications & Ordering
| Code | Chain Size | Nominal Dia (mm) | Pitch (in.) | Inside Width (in.) | Outside Width (in.) | WLL (lbs) | Breaking Load (lbs) | Drum Length (ft) | Weight (lbs/ft) |
|---|---|---|---|---|---|---|---|---|---|
| WOX 4-6 | 5/32" | 4 | 0.47 | 0.23 | 0.58 | 900 | 3,597 | 200 | 0.88 |
| WOX 5-6 | 3/16" | 5 | 0.59 | 0.29 | 0.73 | 1,400 | 5,620 | 200 | 1.34 |
| WOX 6-6 | 7/32" | 6 | 0.71 | 0.31 | 0.85 | 2,000 | 8,430 | 200 | 1.94 |
| WOX 7-6 | 9/32" | 7 | 0.83 | 0.37 | 0.99 | 2,700 | 11,240 | 200 | 2.62 |
| WOX 8-6 | 5/16" | 8 | 0.94 | 0.42 | 1.12 | 3,500 | 14,163 | 200 | 3.37 |
| WOX 10-6 | 3/8" | 10 | 1.18 | 0.53 | 1.42 | 5,500 | 22,481 | 200 | 5.29 |
| WOX 13-6 | 1/2" | 13 | 1.53 | 0.69 | 1.84 | 9,300 | 38,217 | 200 | 8.90 |
| WOX 16-6 | 5/8" | 16 | 1.89 | 0.85 | 2.27 | 13,900 | 56,202 | 150 | 13.23 |
| WOX 20-5 | 3/4" | 20 | 2.36 | 1.06 | 2.83 | 17,600 | 70,590 | 50 | 20.50 |
| WOX 26-4+ | 1" | 26 | 3.07 | 1.38 | 3.68 | 26,500 | 105,885 | – | 35.71 |
All data per manufacturer specifications. Pewag WOX Grade 63 chain and corresponding Grade 63 fittings (AWI, CWI, etc.) must be size-matched to form a complete Grade 63 lifting assembly.
