TOBW Chain Slings
These triple leg chain slings are built using Pewag's specialized BW plate hooks, which are designed specifically for the lifting of steel plate, but can also be used on stacks of metal or timber. Based on Pewag's recommendations, we only offer them on three and four leg slings to ensure proper load stability. Also be sure to keep an eye on lifting angles so that your hooks maintain a proper bite. Plate hooks are attached at bottom of sling using a coupling link that securely connects to the closed eye, making a very sure connection. Made from Grade 100 alloy steel, safety factor of 4:1.
| SKU | Chain Diameter | Length (ft) | WLL 60º (lbs) | WLL 45º (lbs) | Weight (lbs) | Price | Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 9/32TOBWX05-10MC | 9/32" (1/4") | 5 | 11200 | 9100 | 26.44 | $1,048.00 |
|
||||
| 9/32TOBWX10-10MC | 9/32" (1/4") | 10 | 11200 | 9100 | 38 | $1,112.00 |
|
||||
| 9/32TOBWX15-10MC | 9/32" (1/4") | 15 | 11200 | 9100 | 49.54 | $1,174.00 |
|
||||
| 9/32TOBWX20-10MC | 9/32" (1/4") | 20 | 11200 | 9100 | 61.09 | $1,238.00 |
|
||||
| 5/16TOBWX05-10MC | 5/16" | 5 | 14800 | 12100 | 32.2 | $1,110.00 |
|
||||
| 5/16TOBWX10-10MC | 5/16" | 10 | 14800 | 12100 | 46.75 | $1,195.00 |
|
||||
| 5/16TOBWX15-10MC | 5/16" | 15 | 14800 | 12100 | 61.3 | $1,280.00 |
|
||||
| 5/16TOBWX20-10MC | 5/16" | 20 | 14800 | 12100 | 75.85 | $1,366.00 |
|
||||
| 3/8TOBWX05-10MC | 3/8" | 5 | 22900 | 18700 | 53.37 | $1,510.00 |
|
||||
| 3/8TOBWX10-10MC | 3/8" | 10 | 22900 | 18700 | 76.02 | $1,609.00 |
|
||||
| 3/8TOBWX15-10MC | 3/8" | 15 | 22900 | 18700 | 99 | $1,708.00 |
|
||||
| 3/8TOBWX20-10MC | 3/8" | 20 | 22900 | 18700 | 121 | $1,807.00 |
|
||||
| 1/2TOBWX05-10MC | 1/2" | 5 | 39000 | 31800 | 96 | $2,102.00 |
|
||||
| 1/2TOBWX10-10MC | 1/2" | 10 | 39000 | 31800 | 134.19 | $2,261.00 |
|
||||
| 1/2TOBWX15-10MC | 1/2" | 15 | 39000 | 31800 | 172.14 | $2,420.00 |
|
||||
| 1/2TOBWX20-10MC | 1/2" | 20 | 39000 | 31800 | 210.09 | $2,577.00 |
|
||||
| 5/8TOBWX05-10MC | 5/8" | 5 | 58700 | 47900 | 166.09 | $4,150.00 |
|
||||
| 5/8TOBWX10-10MC | 5/8" | 10 | 58700 | 47900 | 225.19 | $4,380.00 |
|
||||
| 5/8TOBWX15-10MC | 5/8" | 15 | 58700 | 47900 | 284.29 | $4,609.00 |
|
||||
| 5/8TOBWX20-10MC | 5/8" | 20 | 58700 | 47900 | 343.39 | $4,839.00 |
|
||||
Products
SKU:
9/32TOBWX05-10MC
Chain Diameter
:
9/32" (1/4")
Length (ft)
:
5
WLL 60º (lbs)
:
11200
WLL 45º (lbs)
:
9100
Weight (lbs)
:
26.44
Price:
$1,048.00
SKU:
9/32TOBWX10-10MC
Chain Diameter
:
9/32" (1/4")
Length (ft)
:
10
WLL 60º (lbs)
:
11200
WLL 45º (lbs)
:
9100
Weight (lbs)
:
38
Price:
$1,112.00
SKU:
9/32TOBWX15-10MC
Chain Diameter
:
9/32" (1/4")
Length (ft)
:
15
WLL 60º (lbs)
:
11200
WLL 45º (lbs)
:
9100
Weight (lbs)
:
49.54
Price:
$1,174.00
SKU:
9/32TOBWX20-10MC
Chain Diameter
:
9/32" (1/4")
Length (ft)
:
20
WLL 60º (lbs)
:
11200
WLL 45º (lbs)
:
9100
Weight (lbs)
:
61.09
Price:
$1,238.00
SKU:
5/16TOBWX05-10MC
Chain Diameter
:
5/16"
Length (ft)
:
5
WLL 60º (lbs)
:
14800
WLL 45º (lbs)
:
12100
Weight (lbs)
:
32.2
Price:
$1,110.00
SKU:
5/16TOBWX10-10MC
Chain Diameter
:
5/16"
Length (ft)
:
10
WLL 60º (lbs)
:
14800
WLL 45º (lbs)
:
12100
Weight (lbs)
:
46.75
Price:
$1,195.00
SKU:
5/16TOBWX15-10MC
Chain Diameter
:
5/16"
Length (ft)
:
15
WLL 60º (lbs)
:
14800
WLL 45º (lbs)
:
12100
Weight (lbs)
:
61.3
Price:
$1,280.00
SKU:
5/16TOBWX20-10MC
Chain Diameter
:
5/16"
Length (ft)
:
20
WLL 60º (lbs)
:
14800
WLL 45º (lbs)
:
12100
Weight (lbs)
:
75.85
Price:
$1,366.00
SKU:
3/8TOBWX05-10MC
Chain Diameter
:
3/8"
Length (ft)
:
5
WLL 60º (lbs)
:
22900
WLL 45º (lbs)
:
18700
Weight (lbs)
:
53.37
Price:
$1,510.00
SKU:
3/8TOBWX10-10MC
Chain Diameter
:
3/8"
Length (ft)
:
10
WLL 60º (lbs)
:
22900
WLL 45º (lbs)
:
18700
Weight (lbs)
:
76.02
Price:
$1,609.00
SKU:
3/8TOBWX15-10MC
Chain Diameter
:
3/8"
Length (ft)
:
15
WLL 60º (lbs)
:
22900
WLL 45º (lbs)
:
18700
Weight (lbs)
:
99
Price:
$1,708.00
SKU:
3/8TOBWX20-10MC
Chain Diameter
:
3/8"
Length (ft)
:
20
WLL 60º (lbs)
:
22900
WLL 45º (lbs)
:
18700
Weight (lbs)
:
121
Price:
$1,807.00
SKU:
1/2TOBWX05-10MC
Chain Diameter
:
1/2"
Length (ft)
:
5
WLL 60º (lbs)
:
39000
WLL 45º (lbs)
:
31800
Weight (lbs)
:
96
Price:
$2,102.00
SKU:
1/2TOBWX10-10MC
Chain Diameter
:
1/2"
Length (ft)
:
10
WLL 60º (lbs)
:
39000
WLL 45º (lbs)
:
31800
Weight (lbs)
:
134.19
Price:
$2,261.00
SKU:
1/2TOBWX15-10MC
Chain Diameter
:
1/2"
Length (ft)
:
15
WLL 60º (lbs)
:
39000
WLL 45º (lbs)
:
31800
Weight (lbs)
:
172.14
Price:
$2,420.00
SKU:
1/2TOBWX20-10MC
Chain Diameter
:
1/2"
Length (ft)
:
20
WLL 60º (lbs)
:
39000
WLL 45º (lbs)
:
31800
Weight (lbs)
:
210.09
Price:
$2,577.00
SKU:
5/8TOBWX05-10MC
Chain Diameter
:
5/8"
Length (ft)
:
5
WLL 60º (lbs)
:
58700
WLL 45º (lbs)
:
47900
Weight (lbs)
:
166.09
Price:
$4,150.00
SKU:
5/8TOBWX10-10MC
Chain Diameter
:
5/8"
Length (ft)
:
10
WLL 60º (lbs)
:
58700
WLL 45º (lbs)
:
47900
Weight (lbs)
:
225.19
Price:
$4,380.00
SKU:
5/8TOBWX15-10MC
Chain Diameter
:
5/8"
Length (ft)
:
15
WLL 60º (lbs)
:
58700
WLL 45º (lbs)
:
47900
Weight (lbs)
:
284.29
Price:
$4,609.00
SKU:
5/8TOBWX20-10MC
Chain Diameter
:
5/8"
Length (ft)
:
20
WLL 60º (lbs)
:
58700
WLL 45º (lbs)
:
47900
Weight (lbs)
:
343.39
Price:
$4,839.00
