Deuer 2" Sheave for 3/16" Wire Rope - 480 lbs WLL
Made in the United States of America!
Need it fast? We stock many items, but some rigging and safety gear has longer lead times. Contact us before placing urgent orders.
Earn rewards points.
CA Prop 65
Product Description
Deuer Sheaves with Bearing – Zinc-Plated Steel
The Deuer Sheaves with Bearing are precision-built for smooth cable motion and long-lasting performance. Made from zinc-plated steel for corrosion resistance, these sheaves feature bronze bushings with precision bearings that ensure quiet, efficient operation under load. Smaller models have solid sides for compact strength, while the larger sizes feature lightening holes to reduce weight without sacrificing capacity — a thoughtful design difference that enhances usability in both fixed and portable setups.
Key Features:
- Made from zinc-plated steel for corrosion and wear resistance
- Precision bearing with bronze bushing for smooth, low-friction cable travel
- Solid-sided design on small models for durability in tight spaces
- Larger models feature lightening holes to minimize weight while maintaining strength
- Ideal for light-duty lifting, guiding, and tensioning applications
Specifications:
| Model | Sheave Dia. × Bore (in.) | Max Cable Size (in.) | Capacity (lbs) | Weight Each |
|---|---|---|---|---|
| DB-15S | 1½ × 5/16 | 1/4 | 420 | 3 oz |
| DB-20S | 2 × 5/16 | 1/4 | 480 | 6 oz |
| DB-25S | 2½ × 5/16 | 1/4 | 550 | 8 oz |
| DB-30S | 3 × 5/16 | 5/16 | 650 | 9 oz |
| DB-35S | 3½ × 5/16 | 5/16 | 1250 | 13 oz |
| (Larger sheaves with lightening holes) | ||||
| DB-40S | 4 × 1/2 | 5/16 | 1400 | 1.15 lbs |
| DB-50S | 5 × 1/2 | 1/4 | 1750 | 1.65 lbs |
| DB-60S | 6 × 1/2 | 1/4 | 1960 | 2.10 lbs |
All dimensions are in inches. Capacities are based on maximum recommended working loads for properly aligned systems. Zinc plating offers corrosion resistance for both indoor and outdoor use.
