Cartec 1/2" Grade 100 Clevis Foundry Hook - 15,000 lbs WLL

Cartec

Cartec 1/2" Grade 100 Clevis Foundry Hook - 15,000 lbs WLL

SKU:
AMH-CYFX13
Made in Italy.

Made in Italy.

This product is rated for overhead lifting.

This product is rated for overhead lifting.

This product usually ships out in just 1 - 2 days.

This product usually ships out in just 1 - 2 days.

Earn XX rewards points

Earn
rewards points.

CA Prop 65

This product may expose you to substances that are known to the State of California to cause cancer or reproductive harm. - https://www.P65warnings.ca.gov

$161.00

Product Description

Cartec CYFX Grade 100 Clevis Foundry Hooks – Direct-Connect Hooks for Chain Slings

The Cartec CYFX series of Grade 100 clevis foundry hooks offers a strong, latch-free solution for overhead lifting applications using chain slings. Designed for permanent integration into sling assemblies, CYFX hooks attach directly to chain without the need for coupling links. Their wide open-throat design makes them ideal for quickly engaging oversized or irregularly shaped loads.

Forged from durable alloy steel and rated for overhead lifting, the CYFX model is commonly used in foundries, steel yards, and other industrial environments where speed and durability are essential.

Key Features:

  • Model: CYFX – Clevis-style foundry hook
  • Grade 100 alloy steel: Forged for high-strength lifting and industrial durability
  • Clevis connection: Mounts directly to chain for a secure, low-profile fit
  • Open-throat design: Simplifies engagement with large or awkward loads
  • No latch: Ideal for applications where fast hook-on and release are required

Size & Working Load Limit Range:

Available in sizes from 7/32" to 5/8", with working load limits ranging from 3,000 lbs to 22,600 lbs.

Purpose-Built for Chain Rigging

The Cartec CYFX clevis foundry hook is a dependable solution for riggers looking to streamline chain sling assemblies while maintaining fast, secure lift capabilities in rugged environments.

View AllClose

Specifications

MPN
CYFX13
Chain Diameter
1/2"
Type
Foundry
Material
Grade 100 Alloy Steel
Color
Orange
WLL (lbs)
15000
Safety Factor
4:1
Overhead Lifting Rated
Yes
Reach (B-B)
5.83"
Throat Opening
3.50"
Attachment Method
Clevis
Approx. Weight (lbs)
7.94
View AllClose

Safety Notice

Although Bishop Lifting strives to manufacture and sell the highest quality rigging and safety gear, use of the gear is dangerous if not used correctly by competent trained professionals. Bishop Lifting disclaims any liability resulting from the misuse of its rigging and safety gear. Please take a moment to more thoroughly review our disclaimer.

Bishop Lifting rigging and safety gear is only intended to be used by competent trained professionals. Misuse of the rigging and safety gear can result in serious injury up to and including loss of life. As such, Bishop Lifting disclaims liability for any misuse or incorrect product selection by our customers.

Rigging and safety gear purchased from Bishop Lifting should be used in strict accordance with all industry and OSHA standards. At no time should rigging or safety gear be used beyond its certified load ratings (aka Working Load Limits). Normal wear and tear should be expected with use of rigging and safety gear; therefore, all gear should be thoroughly inspected before each and every use. Worn or unsafe rigging and safety gear should never be used.
