Suncor 5/16" 316 Stainless Steel Chain - 1900 lbs WLL
This product is imported. Country of Origin subject to change.
Need it fast? We stock many items, but some rigging and safety gear has longer lead times. Contact us before placing urgent orders.
This product is not returnable.
Earn rewards points.
CA Prop 65
Product Description
Suncor Economy Import Stainless Chain – 304 / 316 Stainless Steel (Sold by the Foot)
The Suncor Economy Import Chain is offered in both 304 and 316 stainless steel for excellent corrosion resistance and durability in marine and industrial environments. This welded and polished chain is a dependable choice for general utility, tie-down, and attachment applications where stainless performance is needed.
Important: All measurements are nominal and for reference purposes only. Chain should be checked or measured for compatibility when used with other components. Not rated for overhead lifting. Working loads are based on gradual pull, not shock loads.
Key Features:
- Available in 304 or 316 stainless steel
- Welded and polished economy import chain (similar to NACM industrial chain)
- Ideal for marine and industrial utility applications
- Sold by the foot (bulk drum items omitted)
- Working loads are based on gradual pull (not shock loads)
Specifications – Economy Import Stainless Chain (Sold by the Foot)
| Item Number | Chain Size | Inside Width (A) | Inside Length (B) | WLL (lb) | Weight (lb/ft) |
|---|---|---|---|---|---|
| 304 Stainless Steel Chain | |||||
| S660-03 | 1/8" | 0.15" | 0.90" | 375 | 0.23 |
| S660-05 | 3/16" | 0.21" | 0.97" | 800 | 0.32 |
| S660-07 | 1/4" | 0.27" | 1.22" | 1,300 | 0.57 |
| S660-08 | 5/16" | 0.32" | 1.25" | 1,900 | 0.92 |
| S660-10 | 3/8" | 0.40" | 1.34" | 2,650 | 1.50 |
| 316 Stainless Steel Chain | |||||
| S660-A-03 | 1/8" | 0.15" | 0.90" | 375 | 0.23 |
| S660-A-05 | 3/16" | 0.21" | 0.97" | 800 | 0.32 |
| S660-A-06 | 1/4" | 0.27" | 1.22" | 1,300 | 0.57 |
| S660-A-08 | 5/16" | 0.32" | 1.25" | 1,900 | 0.92 |
| S660-A-10 | 3/8" | 0.40" | 1.34" | 2,650 | 1.50 |
| S660-A-13 | 1/2" | 0.52" | 1.67" | 4,500 | 2.80 |
All dimensions are nominal (+/- 3%) and subject to change without notice. For reference purposes only—verify compatibility when pairing with other components. Not rated for overhead lifting. Working loads are based on gradual pull, not shock loads.
Specifications
Related Items
Related Products
Suncor
Suncor 5/16" 304 Stainless Steel Chain - 1900 lbs WLL
Suncor
Suncor 1/2" 316 Stainless Steel Chain - 4500 lbs WLL
Suncor
Suncor 3/8" 316 Stainless Steel Chain - 2650 lbs WLL
Suncor
Suncor 5/16" 316 Stainless Steel Swivel Hook w/ Latch - 1430 lbs WLL
Suncor
Suncor 9/32" (1/4") 316 Stainless Steel Chain - 1300 lbs WLL
Safety Notice
Although Bishop Lifting strives to manufacture and sell the highest quality rigging and safety gear, use of the gear is dangerous if not used correctly by competent trained professionals. Bishop Lifting disclaims any liability resulting from the misuse of its rigging and safety gear. Please take a moment to more thoroughly review our disclaimer.
Bishop Lifting rigging and safety gear is only intended to be used by competent trained professionals. Misuse of the rigging and safety gear can result in serious injury up to and including loss of life. As such, Bishop Lifting disclaims liability for any misuse or incorrect product selection by our customers.
Rigging and safety gear purchased from Bishop Lifting should be used in strict accordance with all industry and OSHA standards. At no time should rigging or safety gear be used beyond its certified load ratings (aka Working Load Limits). Normal wear and tear should be expected with use of rigging and safety gear; therefore, all gear should be thoroughly inspected before each and every use. Worn or unsafe rigging and safety gear should never be used.
